Speed-x 9700 2d Cmos Desktop Barcode Scanner

Overview\

The Speed-X 9700 is a high-performance scanning platform powered by leading CMOS image recognition technology and an intelligent recognition system. It features a compact design and an attractive appearance, delivering efficient reading capabilities to ensure an excellent user experience. This versatile device effortlessly scans universal 1D and 2D barcodes across paper, goods, screens, and various other media types.\

Key Features\

\
• Large window design with a large viewing angle and ultra-sensitive auto-sense scanning.\
\
• Easily reads all mainstream 1D and 2D barcodes in the market.\
\
• Supports multiple languages and systems.\
\
• Widely used in supermarkets, chain stores, and other retail environments.\
\

Specifications\

\
• \Scan Type:\ CMOS\
\
• \Light Source:\ Red Light LED 625±10nm (aim), 5600K LEDs (lighting)\
\
• \CPU:\ 32-bit\
\
• \Resolution:\ 1280\*800\
\
• \Resolution Limit:\ ≥5mil/0.127mm (PCS90%, Code 39)\
\
• \Depth of Field:\ 0mm - 450mm\
\
• \Scan Mode:\ Auto Sense\
\
• \Scan Angle:\ Roll ±360°, Pitch ±80°, Skew ±70° (PCS90%, Code 39, 10mil/0.25mm)\
\
• \Print Contrast Signal:\ ≥25%\
\
• \Ambient Light:\ Dark environment, indoor natural light\
\
• \1D Symbologies:\ Code 39, Codablock, Codabar, Code 128/EAN 128, Code 93, Code 11, Interleave 2 of 5, Matrix 2 of 5, EAN.UCC Composite, Straight 2 of 5 Industrial, Straight 2 of 5, RSS, Plessey Code, MSI Code, Telepen, UPC-A, UPC-E0, EAN/JAN-13, BPO, Planet, TLC39, etc.\
\
• \2D Symbologies:\ PDF417, QR CODE, MICRO QR, DATAMATRIX, AZTEC CODE, HanXin, Maxicode, Micro PDF417, etc.\
\
